The TREMOR3™ reticle is designed to maximize the speed and accuracy of marksmen. Its unique use of patented features gives users the capability to quickly estimate the range to targets while also giving the user wind speed and drop correction information for fast and accurate Second Shot Corrections.
TREMOR3™ FFP reticle* Made in Japan
Removable Magnification Throw Lever
30mm one piece tube
Tenebraex™ Tactical Tough™ Flip Up Covers
Precision Turret System (PTS)
Zero Stop
Capped Precision Windage Turret
Glass etched reticle
Weathershield lens coating
Argon Purged
SPECIFICATIONS
Focal Plane First (FFP)
Reticle calibrated magnification power (SFP only) N/A
Magnification Range 4-24x
Objective Lens Diameter 50mm
Maintube Diameter 30mm
Zero Stop Yes
Turret Index Value 0.1 MRAD
Internal Elevation Adjustment 23 MRAD
Internal Windage Adjustment 20 MRAD
Parallax Adjustment Range 20 Meters – Infinity
Exit Pupil Diameter Low: 8.6mm; High: 2.1mm
Eye Relief 92mm
Field Of View @100 Meters Low:9.7m; High: 1.6m
Objective Outer Diameter 59mm
Ocular Outer Diameter 43.6mm
Weight 790g
Available Reticles RMG FFP Illuminated reticle
TREMOR3™ FFP reticle* Made in Japan
Illumination Yes
